PV-ezRack Splice for Elite Rail, Black Anodized

Application : Splicing Elite rails of PV-ezRack Mounting System

Dimensions : L200mm W11.2mm H50mm Weight 0.086 Kg

Packaging : 60 units per pack, 4 packs (240 units) per carton, 60 cartons (14,400 units) per pallet

Packaging Dimension : L397 W267 H345mm (carton dimension)

Weight : ER-SP-ELT: 0.086 Kg; 21.86 Kg (carton weight) ER-SP-ELT/BA: 0.086 Kg; 21.86 Kg (carton weight)

Material : Main part: AL6005-T5 Connection Clip: SUS304 Finish Anodized (no less than 10 μm, excluding machined surfaces)

Standard : AS NZS1170.2-2021
