2023 RIFT ZONE JR 26

REAL SINGLETRACK RIDING

KEEPING UP WITH THE PARENTS

FUN!

The Hawk Hill 26 and Hawk Hill Jr are for the ambitious kid looking to keep up with the adults and push the boundaries of the local bike park on a ride just as capable as its full size counterpart.

Download owner's manual (PDF)

Please note - specifications & price subject to change without prior notice. 01. FRAME All New Series 3 6061 Aluminum Frame, 26" Wheels, 130mm Travel, MultiTrac Suspension Platform, 135mm Open Dropout (Upgradeable to 142x12mm Thru-Axle), 73mm Threaded BB 02. FORK X-Fusion Velvet RLC 26", 130mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle 03. SHOCK X-Fusion O2 Pro R, 190x51mm, Custom Tune, M8x22.2mm Hardware 04. RIMS Marin Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible 05. HUB REAR Forged Alloy, 135mm, Quad Sealed Bearings, Centerlock Disc, 32H 06. HUB FRONT Forged Alloy, 100x15mm, Centerlock Disc, 32H 07. SPOKES 14g Stainless Steel 08. TIRES Vee Tire Co, Flow Snap 26x2.4", Tackee Compound, Wire Bead 09. DERAILLEUR REAR Shimano Deore, 11 Speed, SGS 10. SHIFT LEVER Shimano Deore, 11-Speed, SL-5100R 11. CRANKSET Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing, 170mm Length 12. BOTTOM BRACKET External Sealed Cartridge Bearings 13. CHAIN KMC X-11 Silver and Black 14. CASSETTE SunRace, 11-Speed, 11-51T, ED Black 15. BRAKES FRONT Shimano MT-201 Hydraulic Disc, 180mm Rotor 16. BRAKES REAR Shimano MT-201 Hydraulic Disc, 160mm Rotor 17. BRAKE LEVERS Shimano BL-MT201 Hydraulic 18. HANDLEBAR Marin Mini-Riser, 6061 Double Butted Aluminum, 12mm Rise, 720mm Width, 4º Up, 9º Back 19. STEM Marin 3D Forged Alloy, 35mm 20. GRIPS Marin MTN, Closed End 21. HEADSET FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2" 22. SEATPOST Marin Alloy, 30.9mm 23. SADDLE Marin Speed Concept 24. EXTRAS Closed 9-12 Thru-Axle QR System
