*6" Sykes CP150iC-AR Pumpset
Lead time – TBA
o 150mm / 6" Suction Flange
o 150mm / 6" Discharge Flange
o 76mm Solids handling
o CP150iC Automatic Compressor Priming Pump End
o 255 mm Diameter Impeller
o Mechanical Seal - Oil Lubricated Hard Faced Capable of Running Dry for Extended Periods
o 150mm / 6" Ball Type NRV
o 404D-22T – Perkins Diesel Engine
o S27 Control Panel c/w Engine Protection & E Stop & Float level capability
o Variable Speed engine performing
o 205L Polyethylene Fuel Tank / Fully Bunded
o Galvanised Steel Base
o Single Point Lift Frame
o Mine Safe Radiator Cap, Lockable Fuel Cap & 12v Battery o Fuel efficient at 4.0L/h @ 1600 RPM
o Maximum Capacity 145 L’s / 522m3/hour
Fuel Rate @ BEP 1,600rpm 4.0L/hr giving you 51 hours run time at 1600RPM
×
