SecurONE Complete Surveillance Kit
The SecurONE kit is a complete system for local as well as remote
surveillance right out of the box. It features a state of the art H.264
digital video recording unit, four top of the line Sony CCD security
cameras, a premium 1TB Seagate brand hard disk drive, and all the
accessories you'll need DVR SPECIFICATIONS
- Operating system: Embedded Linux
- Main function: Live display, Recording, Playback, Remote access
- Video display: Single camera or Quadrant split screen
- Recording mode: Continuous / Motion detection
- Overwrite mode: Cycle / Stop on full
- Playback: Single channel / 4 channel simultaneous !
- Hard Drive: FREE 1TB Seagate barracuda 7200 rpm HDD included
- Video systems: PAL/NTSC (Auto)
- Security camera BNC inputs: 4
- TV display BNC outputs: 2
- Audio sensor AV input: 1
- Speaker output AV: 1
- RJ-45 network adapter: 1
- USB 2.0 ports: 2 (mouse, keyboard, flash drive, external HDD)
- RS485 port: 1
- VGA port: 1
- Video recording standard: H.264, true MPEG-4 compression
- Video size (depending on quality selected): 25MB - 450MB /hour
- Frames per second: 100 (total for 4 cameras)
- Motion detection support: YES
- Network function support: YES
- PTZ function support: YES
- Mobile phone browsing support: YES
Security camera type: DOME
- Image sensors: Premium 1/3 inch SONY CCD
- Shutter speed: 1/50th of a second
- TV lines: 420
- Color system: PAL
- Infrared sensors: 24 LED (6 mm)
- IR distance: 10 m
- Minimum illumination: 0 Lux
- Pixel resolution: 512 x 582
- AGC: AUTO
- Backlight compensation: AUTO
- White balance: AUTO
- Cable Length: 18 M
Connection: RJ-45 Port (10/100M)
- IP address: Static / DHCP
- Remote browsing: Internet Explorer
- Capture format: H.264 MP4
- Certifications: CE, FCC, RoHS
Package Contents:
- Digital Video Recorder unit
- 12V/4A Power Supply
- Dome Cameras x 4
- 5.5V/1A Power Supply x 4
- 18 meter BNC Cable x 4
- Remote Control
- Mouse
Software
- CD
User Manual - English
- Mounting Screws
- Power Connector
